Specification
|
Fan Type |
High Volume Low Speed |
|
Airflow |
600,000 CMH / 353,000 CFM |
|
Area Coverage Sq. Ft (upto) |
7000 |
|
Pressure (Pa) |
21 |
|
Power (Kw) |
0.75 |
|
V/PH/Hz |
220/1/50 |
|
Rated Current(A) |
10.2 |
|
Fan Type |
Axial |
|
Fan Diameter (mm) |
5000 |
|
Fan Speed |
Multi |
|
Fan Rotation |
20-80 rpm |
|
Motor Type |
Permanent Magnet Synchronous Motor |
|
Fan Blade Fins |
5 |
|
Ingress Protection |
IP54 |
|
Air Velocity (m/s) |
4 |
|
Net Weight(kg) |
77 |
|
Body Material |
Aluminum Alloy |
|
Fan Blade Material |
Aluminium-Magnesium Alloy |
|
Color |
Grey |
|
Controller |
On/Off with Variable Speed |
|
Group Control |
Optional |
|
Drive |
Direct |
|
Noise(dBA) |
≤38 |
|
Life Expectancy |
20 Years |
|
Standard Warranty (onsite) |
1 Year |
|
Extended Warranty (RMA-Based) |
4 Years |
